Demonstration mechanics
These demonstration mechanics are commercially used products that were mainly used for demonstrations, viewings or application tests. Please contact us for availability, prices or other questions.
- AT_2020_08_00035
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 15 | 33.1 |
Working area-reach [mm|in]: | 1682 | 66.2 |
Mounting position: | Floor, Ceiling, Wall, Angle |
This robot mechanics is characterized by the hollow axes 4 and 6. The large boreholes allow media supplies for end effectors. No installation need of motor and encoder cables for axes 5 and 6 as spirals around the fourth axis. Service life is significant increased.
|
Field of application: | CNC Robotics, Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 30 | 66.1 |
Working area-reach [mm|in]: | 1665 | 65.6 |
Mounting position: | Floor, Ceiling, Wall, Angle |
This robot mechanics was developed for applications that demand high rigidity, good vibration damping and maximum precision. It is sealed against abrasive dusts, liquids, etc. and can be pressurized with sealing air.
|
- AT_2024_02_00270
Field of application: | Standard (not hygienic), Surface processing |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 20 | 44.1 |
Working area-reach [mm|in]: | 1720 | 67.7 |
Mounting position: | Floor, Ceiling, Wall, Angle |
This robot mechanics was specially developed for grinding, polishing and deburring applications and is characterized by the offset wrist (angled hand). The robot has a compact, lightweight design. ...
|
- AT_2020_02_00031
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 45 | 99.2 |
Working area-reach [mm|in]: | 2118 | 83.4 |
Mounting position: | Floor, Ceiling |
Increased precision through the use of a reinforced gearbox between the base frame and rotating column (axis 1) with increased torque, increased tilting rigidity and reduced backlash
|
- AT_2021_11_00097
- AT_2021_06_00043
Field of application: | CNC Robotics, Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 2 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 30 | 66.1 |
Working area-reach [mm|in]: | 1035 | 40.7 |
Mounting position: | Floor, Ceiling, Wall, Angle |
- AT_2024_04_00299
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 850 | 1873.9 |
Working area-reach [mm|in]: | 3219 | 126.7 |
Mounting position: | Floor |
- AT_2024_10_00325
- AT_2024_07_00307
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 6 | 13.2 |
Working area-reach [mm|in]: | 1215 | 47.8 |
Mounting position: | Floor, Ceiling, Wall, Angle |
- AT_2021_09_00095
- AT_2019_06_00015
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 3 | 6.6 |
Working area-reach [mm|in]: | 1557 | 61.3 |
Mounting position: | Floor, Ceiling |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 3 |
Nominal payload [kg|lbs]: | 30 | 66.1 |
Working area-reach [mm|in]: | 2257 | 88.9 |
Mounting position: | Floor, Ceiling |
- AT_2024_01_00268
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 1 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 60 | 132.3 |
Working area-reach [mm|in]: | 810 | 31.9 |
Mounting position: | Wall |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 6 | 13.2 |
Working area-reach [mm|in]: | 1000 | 39.4 |
Working height [mm|in]: | 400 | 15.7 |
Mounting position: | Floor, (Ceiling), Wall |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 6 | 13.2 |
Working area-reach [mm|in]: | 600 | 23.6 |
Working height [mm|in]: | 200 | 7.9 |
Mounting position: | Floor, (Ceiling), Wall |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 0 |
Nominal payload [kg|lbs]: | 12 | 26.5 |
Working area-diameter [mm|in]: | 1200 | 47.2 |
Working height outside [mm|in]: | 300 | 11.8 |
Number of the tool actuation (telescopic shaft(s)): | 1 |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 0 |
Nominal payload [kg|lbs]: | 20 | 44.1 |
Working area-diameter [mm|in]: | 1200 | 47.2 |
Working height outside [mm|in]: | 300 | 11.8 |
Number of the tool actuation (telescopic shaft(s)): | 1 |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 3 | 6.6 |
Working area-diameter [mm|in]: | 1200 | 47.2 |
Working height outside [mm|in]: | 250 | 9.8 |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 3 | 6.6 |
Working area-diameter [mm|in]: | 1200 | 47.2 |
Working height outside [mm|in]: | 200 | 7.9 |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 20 | 44.1 |
Working area-diameter [mm|in]: | 1400 | 55.1 |
Working height outside [mm|in]: | 350 | 13.8 |
Field of application: | Standard (not hygienic) |
Translatory Degrees of Freedom (X,Y,Z): | 3 |
Rotational Degrees of Freedom (α,ß,γ): | 1 |
Nominal payload [kg|lbs]: | 50 | 110.2 |
Working area-diameter [mm|in]: | 1600 | 63.0 |
Working height outside [mm|in]: | 400 | 15.7 |
