Coming soon
Here you will find an overview of current product developments. Please contact us if you have any requirements: info@autonox.com
Article number: AT_00012
| Field of application: | Standard (not hygienic) |
| Translatory Degrees of Freedom (X,Y,Z): | 3 |
| Rotational Degrees of Freedom (α,ß,γ): | 3 |
| Nominal payload [kg|lbs]: | 15 | 33.1 |
| Working area-reach [mm|in]: | 1682 | 66.2 |
| Mounting position: | Floor, Ceiling, Wall, Angle |
|
This robot mechanics is characterized by the hollow axes 4 and 6. The large boreholes allow media supplies for end effectors. No installation need of motor and encoder cables for axes 5 and 6 as spirals around the fourth axis. Service life is significant increased.
|
|
Article number: AT_00016-SE01
| Field of application: | CNC Robotics, Standard (not hygienic) |
| Translatory Degrees of Freedom (X,Y,Z): | 3 |
| Rotational Degrees of Freedom (α,ß,γ): | 3 |
| Nominal payload [kg|lbs]: | 150 | 330.7 |
| Working area-reach [mm|in]: | 2407 | 94.8 |
| Mounting position: | Floor, Ceiling |
|
The use of secondary encoders is prepared for axes 1-6. This robot mechanics was developed for applications that demand high rigidity, good vibration damping and maximum precision. It is sealed against abrasive dusts, liquids, etc. and can be pressurized with sealing air. For patent law reasons not available and usable in the USA!
|
|
Article number: AT_00031
| Field of application: | Standard (not hygienic), Surface processing |
| Translatory Degrees of Freedom (X,Y,Z): | 3 |
| Rotational Degrees of Freedom (α,ß,γ): | 3 |
| Nominal payload [kg|lbs]: | 20 | 44.1 |
| Working area-reach [mm|in]: | 1720 | 67.7 |
| Mounting position: | Floor, Ceiling, Wall, Angle |
|
This robot mechanics was specially developed for grinding, polishing and deburring applications and is characterized by the offset wrist (angled hand). The robot has a compact, lightweight design. ...
|
|
Article number: AL_00016
| Field of application: | Standard (not hygienic) |
| Translatory Degrees of Freedom (X,Y,Z): | 3 |
| Rotational Degrees of Freedom (α,ß,γ): | 1 |
| Nominal payload [kg|lbs]: | 6 | 13.2 |
| Working area-diameter [mm|in]: | 1200 | 47.2 |
| Working height outside [mm|in]: | 250 | 9.8 |
Article number: AT_00016
| Field of application: | CNC Robotics, Standard (not hygienic) |
| Translatory Degrees of Freedom (X,Y,Z): | 3 |
| Rotational Degrees of Freedom (α,ß,γ): | 3 |
| Nominal payload [kg|lbs]: | 150 | 330.7 |
| Working area-reach [mm|in]: | 2390 | 94.1 |
| Mounting position: | Floor, Ceiling |
|
This robot mechanics was developed for applications that demand high rigidity, good vibration damping and maximum precision. It is sealed against abrasive dusts, liquids, etc. and can be pressurized with sealing air.
|
|
